News




Leader Instruments, a wholly owned subsidiary of Leader Electronics Corporation, Yokohama, Japan, will showcase the new LT4610 3G/HD/SD multi-format video sync generator on Booth C5109 at the 2016 NAB Show in Las Vegas. Designed for use in broadcast studios, mobile production vehicles, post-production companies and broadcast equipment maintenance facilities, the LT4610 provides an exceptionally wide range of capabilities within a compact 1 RU x 15.75 inches (400 mm) deep footprint.



Test patterns available from the LT4610 include 100% and 75% color bars, multi-format color bars and SDI check fields with user-selectable scrolling in eight combinations of up/down/left/right. Scrolling speed is user adjustable from 1 to 256 pixels or lines. Y/G, Cb/B, Cr/R components can be turned on or off independently for each output channel.

QVGA (320 pixel x 240 line) 24-bit full color bitmap logos can be transferred into the generator via USB memory and added to any test pattern.

The LT4610 can also generate IDs of up to 20 characters for placement at any operator-assigned screen position. ID size is selectable between 32 x 32, 64 x 64, 128 x 128 and 256 x 256 pixel sizes at 100% or 75% intensity, continuous or blinking. IDs can be scrolled to the left or right.

Safety area markers can be generated to show safe-action area (90%), safe-title area (80%) and/or 4:3 aspect ratio. ID characters, logo mark, safe-area markers and test pattern can be displayed individually, sequentially or simultaneously.

Audio test generation capabilities include silence, 400 Hz, 800 Hz, and 1 kHz at -60 to 0 dBFS in 1dBFS steps, assignable across up to 16 channels for 3G-A/HD/SD and 32 channels for 3G-B. Audio sampling resolution can be selected from 20 or 24 bit at 48 kHz and synchronized with the video signal. Audio clicks can be generated between 1 and 4 seconds or disabled.

The LT4610 has a genlock input and can be synchronized with NTSC/PAL black burst or HD tri-level sync signals. Six independent analog black burst reference signals are provided, which can be changed to tri-level sync. A 48 kHz word clock output and 48 kHz AES/EBU output are also provided for synchronizing audio signals.

Standard support for SNMP via Ethernet makes it easy to integrate the LT4610 into a network environment. Alarms are generated with SNMP and displayed on the front panel when errors do occur.

A redundant power supply with fast automatic switchover is included as standard.

The LT4610SER01 GPS option adds a GPS sync input, 10 MHz CW sync input and timecode input/output functions. The timecode generator can be synchronized to the internal clock or to GPS time Information.  It can be used to create ancillary linear timecode and AES/EBU-embedded timecode synchronized to GPS time information. A holdover function holds the phase and frequency of the output signal so that measurement stays in sync even if the source reference is lost.
