PHABRIX will be launching its QxL 25G IP rasterizer at NAB 2020, booth C9515. The QxL is the world’s most flexible UHD-25G rasterizer, created to address the needs of professional broadcast media IP networks in a compact form factor.


The QxL inherits all the JT-NM Tested features of the Qx with a common look and feel across both platforms. Out of the box, this 10G/25G IP enabled rasterizer supports JT-NM TR 1001-1:2018, 2110-20 (video), 2110-30 (PCM audio), 2110-31 (AES transport), and 2110-40 ANC media flows all with 2022-7 Seamless IP Protection Switching (SIPS), and independent PTP slaves on both media ports for fully-redundant media network operation.

The toolset also provides support for DHCP on all IP ports, unicast DNS-SD, AMWA NMOS IS-04 Discovery and Registration, IS-05 Connection management, system resource, and Network Topology Discovery using Link Layer Discovery protocol (LLDP).

IP media interfaces are provided as standard and SDI media interfaces with optional SDI Eye and Jitter measurement are available as a factory fitted option. The flexible user-friendly GUI provides up to 16 user-configurable windows with presets for rapid visualization of different traffic and workflow configurations.

A suite of operator level IP flow health and PTP monitoring is provided with warnings and alarms. For detailed analysis and debug, the new IP-MEAS toolset provides advanced engineering-grade information including four 2022-7 Packet Interval Time (PIT) displays, media port network statistics, real time measurements of Flow to PTP relationships and latency plus real-time measures of 2110-21 Cinst and Vrx.
